    10 Ton 4A Electric Hydraulic Punching Machine
    10 Ton 4A Electric Hydraulic Punching Machine
    10 Ton 4A Electric Hydraulic Punching Machine

    10 Ton 4A Electric Hydraulic Punching Machine

    1 review(s) | Add your review
    Electric hydraulic punching machine for sale. Power supply 220V (customizable 110V), rated current 4A, 900W motor, output 10 ton. Punching thickness copper/aluminum busbar ≤8mm, iron/steel plate ≤6mm. Standard punching dies 6.5, 9, 13, 17, 20.5, 20.5mm.
    SKU: T-HPM-104
    *
    $622.54
    i h
    Free shipping
    Delivery date: 6-12 days
    Overview

    Portable hydraulic punching machine is a hydraulic hole puncher powered by electric motor, it is used in punching holes for copper busbar, aluminum busbar, steel plate, etc.

    Specification

    Model T-MHP-20
    Output Force 10 Ton
    Rated Voltage 220V (customizable 110V)
    Rated Current 4A
    Motor Power 900W
    Max. Punching Thickness Copper/Aluminum Busbar ≤8mm
    Iron/Steel Plate ≤6mm
    Angle Steel 4-6#
    Throat Depth 40mm
    Punching Speed 2-3s
    Weight 12 kg
    Punching Dies Standard Configuration Φ 6.5mm, 9mm, 13mm, 17mm, 20.5mm.  1 set for each (includes upper die and lower die)

    Structure Diagram of Electric Hydraulic Punching Machine

    Structure of 10 Ton 4A Electric Hydraulic Punching Machine

    Dimension Diagram

    Dimension Diagram of 10 Ton 4A Electric Hydraulic Punching Machine

    Applicable Materials

    Applicable Materials of 10 Ton 4A Electric Hydraulic Punching Machine
