Industrial heavy duty bolt cutters are available in sizes of 14" / 18" / 24" / 30" / 36" / 42" / 48", with hardened and durable CR-V jaw and comfortable non-slip grip, allowing you to easy and efficient to cut through wires, chains, rods, and other metals, xcellent quality, long use life and favorable price.
Specification
Model |
T-DXQ-14 |
T-DXQ-18 |
T-DXQ-24 |
T-DXQ-30 |
T-DXQ-36 |
T-DXQ-42 |
T-DXQ-48 |
Size * |
14" |
18" |
24" |
30" |
36" |
42" |
48" |
Jaw Material |
CR-V steel |
Overall Length |
350mm |
460mm |
600mm |
750mm |
900mm |
1050mm |
1150mm |
Handle Length |
250mm |
370mm |
480mm |
600mm |
72mm |
870mm |
960mm |
Cutting Edge Width |
60mm |
75mm |
90mm |
100mm |
110mm |
130mm |
130mm |
Cutting Capacity |
4mm |
6mm |
8mm |
10mm |
12mm |
14mm |
16mm |
Weight |
0.8kg |
1.4kg |
2.15kg |
3.7kg |
4.6kg |
6.75kg |
7.24kg |
Note: The sizes are approximate.
Bolt Cutters Dimension Drawing
Applications
Tips: What is a Heavy Duty Bolt Cutter Used for?
A heavy duty bolt cutter is a valuable hand tool that cut wires and thicker metallic lines, which is divided into insulated handle bolt cutter, iron handle bolt cutter, pipe hand bolt cutter. In common, electricians usually use insulated handle bolt cutter, which is safety for working. Using an appropriate bolt cutter can easily and effectively adjust wire mesh size to reinforced concrete pad and other routine tasks. The bolt cutter helps break down larger items, make it small enough to put in the garbage can, when you handle shelves or old furniture. The blade of a bolt cutter is made from high quality alloy steel that has long service life, so that you could finish the most difficult cutting jobs. Different sizes of the bolt cutter have different cutting objects. For example, a bolt cutter, size in 14-24 inch can cut larger diameter rods and chains and size in 30-48 inch can handle heavy duty copper cables, steel rods and steel chains. This bolt cutter can turn hard work into easy work.
